12V 25A 2.4G LED Dimmer Controller

2.4G RF Multi Zone Single Color Dimmer (Receiver)

  • Work with MJJC-HMW-WIFI-V02 together
  • Compatiable with MJJC LED Signal Amplifiers
  • 12-24V DC working voltage
  • Used for 12-24 volt constant voltage Single Color led lights
  • 2 Years’ warranty
  • CE/RoHS

DIM Receiver for Multi zone WIFI LED Control Solution.

Wifi BOX just is a effect of a bridge,like a wifi router, work as a senders

MJJC-SZ100-MULTZ-DIM work as a Receiver,connect with Single Color LED Strip Lights, also the receiver section compatible with the MJJC LED signal amplifier for power expansion, to achieve more control of LED lights, in theory, numerous LED amplifiers can be connected.



Technical Parameters:

Receiver, model for separately purchase: MJJC-SZ100-MULTZ-DIM.

Working temperature -20-60℃ Supply voltage DC12~24V
Standby power <1W Connecting mode
Brightness levels 256 Speed levels 100
Net weight 170g Gross weight 200g
External dimension L127*W41*H32 (mm) Output 1 channel
Output current <25A Output power <300W
RF distance ≤30m RF frequency 2.4GHz
Memory function support Effect 3

Multi-zone LED Controller projects

IF you want to look for a Multi-zone RGB Receiver,please kindly kindly click here to check details.
